| Specifications |
|
| Type |
Ax-50 |
| ENGINE TYPE |
2-stroke,horizontal |
| CYLINDER NUMBER |
1 |
| DISPLACEMENT |
49. cc |
| BORE STROKE |
1.6x1.5 |
| COMPRESSION RATIO |
7.2:1 |
| MAX. TORQUE |
2.45n-m/5000 rpm |
| CARBURETOR |
Mikuni AM3 |
| STARTING |
Electric+Kick |
| LUBRICATION |
Autolube |
| LUBRICATION CAPACITY |
2.1 pints |
| TRANSMISSION |
Automatic (C.V.T.) |
| SUSPENSION, front |
Hydraulic |
| SUSPENSION, rear |
unit swing |
| BRAKE, front |
Drum |
| BRAKE, rear |
Drum |
| TIRE, front |
2.75x10 |
| TIRE, rear |
2.75x10 |
| OVERALL DIMENSION |
49"x23"x29" |
| DRY WEIGHT |
101 lbs. |
| MAXIMUM LOAD |
110 lbs. |
| FUEL |
1.1 gal. Unleaded Gasoline |
|
